Lasercutter LS100EX 60W

Item No.GRAV57649
Laser engraving machine LS100EX Gravotech  LS100 EX  laser engraving machinr For signage and small series CO2 laser machine LASER TABLE LS100EX:  Engraving area  610x305mm 60W  The LS100EX CO2 laser machine is a medium-sized machine for engraving and cutting. Its engraving a
Price €21318
excl. tax
Out of stock
This product must be ordered. Please contact us

Leasing alkaen 367,67€ /kk +alv 72kk

Description

Laser engraving machine LS100EX


Gravotech  LS100 EX  laser engraving machinr
For signage and small series CO2 laser machine
LASER TABLE LS100EX:  Engraving area  610x305mm 60W
The LS100EX CO2 laser machine is a medium-sized machine for engraving and cutting. Its engraving area matches the size of ¼ sheet, making it the ideal sign making machine. The gantry laser technology applicable for small industrial series production.
  • SIGN ENGRAVING AND CUTTING MACHINE
    With a working area of 610x305mm exactly matching ¼ sheet size, the LS100EX is a signage engraving and laser cutter above the rest1. Be it plastic, wood, metal, or glass, any signage material can be engraved and cut. This can be your favorite sign making machine, with a large range of consumables available with up to 2 color layers, for a contrasted and professional result.

  • INDUSTRIAL LASER FOR SERIES PRODUCTION
    The large dimension combined with a gantry laser technology makes the LS100 EX the perfect CO2 laser machine for small production series. Load your items or parts to be engraved, and create your engraving job with the Gravostyle software. Several industrial functions are available, such as the Matrix mode or automatic date stamp. Let your laser engraver do the hard work!
    A CO2 source will be perfect for plastics and organic materials such as wood, paper, rubber etc.

Specifications

Delivery time
6 Vk/wk

Reviews (0)

There are no reviews yet.

Technical Specifications

LS100LS100ExLS900LS1000XP
Laser Source / TechnologyCO2CO2, FiberCO2, Fiber, EdgeCO2
Max. object weight15 kg (33.1 lb)20 kg (44.1 lb)25 kg (55.2 lb)25 kg (55.2 lb)
Dimensions (L x W x H)775 mm x 725 mm x 450 mm (30.5 in x 28.5 in x 17.7 in)1025 mm x 725 mm x 450 mm (40.4 in x 28.5 in x 17.7 in)945 mm x 1080 mm x 810 mm (37.2 in x 42.5 in x 31.9 in)1660 mm x 1160 mm x 800 mm (65.4 in x 45.7 in x 31.5 in)
Machine weight43 kg (94.8 lb)70 kg (154.4 lb)From 170 kg to 240 kg (from 374.8 lb to 529.1 lb)220 kg (485 lb)
Automatic Z axis145 mm (5.7 in)145 mm (5.7 in)250 mm (9.8 in)300 mm (11.8 in)
Noise level≤ 70 dB≤ 70 dB≤ 70 dB≤ 66 dB
Point & shootyesyesyesyes
Operating Temperature10 °C - 35 °C (50°F - 95 °F)10 °C - 35 °C (50°F - 95 °F)10 °C - 35 °C (50°F - 95 °F)10 °C - 35 °C (50°F - 95 °F)
Connection to computerUSBUSBUSBUSB
Maximum speedup to 2540 mm/s (100 in/s)up to 2540 mm/s (100 in/s)up to 4000 mm/s (157.5 in/s)up to 4000 mm/s (157.5 in/s)
Laser safety classificationCDRH: Class 2CDRH: Class 2CDRH: Class 2CDRH: Class 2
Beam diameter0.1 mm to 0.4mm (0,004 in to 0,016 in)0.1 mm to 0.4mm (0,004 in to 0,016 in)0.1 mm to 0.4mm (0,004 in to 0,016 in)0.1 mm to 0.4mm (0,004 in to 0,016 in)
SoftwareGravostyleGravostyleGravostyleGravostyle
