Suomi (Suomi)Marking station Hybrid
Item No.H10E160mmLW2
LW2: Fully automated laser marking station Hybrid laser LASER STATION Hybrid The most complete laser station for permanent marking. From unit to small batch production to integration in a robotic cell. Compatible with Fiber, Hybrid, or Green source. TOUCH SCREEN Just press the touch screen and th
Price €28900
excl. tax
Out of stock
This product must be ordered.
Please contact us
Leasing alk. 614,13€/kk + ALV. Leasingkausi 60 kk. Lue lisää
Description
LW2: Fully automated laser marking station Hybrid laser
LASER STATION HybridThe most complete laser station for permanent marking. From unit to small batch production to integration in a robotic cell. Compatible with Fiber, Hybrid, or Green source.
- TOUCH SCREEN
Just press the touch screen and the LW2 laser engraving machine enclosure takes care of the rest! The door closes automatically, the automated laser cutter is positioned at the right focus height, the marking is done in a few seconds and the door opens. This laser station does not require training. All you have to do is prepare your marking sheets and load them into the station via the USB port.
- COMPLETLY SAFE LASER MARKING SYSTEM
The safety of the operator is our priority. The laser marking station is certified as class 1 laser products, meeting all safety requirements, allowing use in unrestricted environments: integrated fail-safe relay, protective glass, door closure security, emergency stop, door fitted with sensors and anti-pinch system, integrated extraction and filtration solution to protect users from dust and smoke. Mechanic and electronics are fully protected in a sealed box. Integrated alarms and controls.
- FLEXIBILE MARKING STATION
Large marking area laser marking system with 3 sided door, marking of a large variety of parts, from small to big parts, from simple to complex shapes. LW2 laser engraving machine enclosure is compatible with all laser sources to offer you the possibility to mark on any type of material. We propose 2 software choices for the creation and control of your marking station to adapt to your needs and various and varied applications: Lasertrace & Laserstyle.
Specifications
- Delivery time
- n 8vk
Reviews (0)
There are no reviews yet.
Tekniset tiedot
| LW2 FIBER | LW2 Green | LW2 HYBRID | |
|---|---|---|---|
| Model | LW2 Fiber | LW2 Green | LW2 Hybrid |
| Laser Technology | Fiber | DPSS | DPSS |
| Max. object size (L x W x H) | 502 mm x 477 mm x 322 mm (19.8 in x 18.8 in x 12.7 in) (depending on the focal length) | 502 mm x 477 mm x 322 mm (19.8 in x 18.8 in x 12.7 in) (depending on the focal length) | 502 mm x 477 mm x 322 mm (19.8 in x 18.8 in x 12.7 in) (depending on the focal length) |
| Max. object weight | 25 kg (55 lbs) | 25 kg (55 lbs) | 25 kg (55 lbs) |
| Power | 20W / 30W / 50W | 5W | 10W / 20W |
| Power Peak | 10 kW | 70 kW | 60 kW |
| Dimensions (L x W x H) | 600 mm x 622 mm x 772 mm (23.6 in x 24.5 in x 30.4 in) | 600 mm x 622 mm x 772 mm (23.6 in x 24.5 in x 30.4 in) | 600 mm x 622 mm x 772 mm (23.6 in x 24.5 in x 30.4 in) |
| Frequency | 30-60 Khz or 2 -200 Khz | Up to 10 - 100 Khz | Up to 10-100 Khz |
| Speed | Up to 10000 mm/s (393,7 in/s) | Up to 3000 mm/s (118,1 in/s) | Up to 3000 mm/s (118,110 in/s) |
| Z axis type | Motorized & Programmable | Motorized & Programmable | Motorized & Programmable |
| Operating Temperature | 10-40°C | 15-35°C | 15-35°C |
| Marking Area - Available lenses | F100: 65 mm x 65 mm (2.6 in x 2.6 in) F160: 110 mm x 110 mm (4.3 in x 4.3 in) F254: 175 mm x 175 mm (6.9 in x 6.9 in) F330: 205 mm x 205 mm (8.1 in x 8.1 in) | F160: 110 mm x 110 mm (4.3 in x 4.3 in) F254: 150 mm x 150 mm (5.9 in x 5.9 in) | F160: 110 mm x 110 mm (4.33 in x 4.33 in) F254: 175 mm x 175 mm (6.89 in x 6.89 in) |
| Z axis stroke | 295mm (11,6 in) | 295mm (11,6 in) | 295mm (11,6 in) |
| Door type | Automatic | Automatic | Automatic |
| Communication interfaces (standard) | Ethernet TCP/IP; Terminal block 8I / 8O; Laser Safety Dedicated I/O; RS232; USB | Ethernet TCP/IP; Terminal block 8I / 8O; Laser Safety Dedicated I/O; RS232; USB | Ethernet TCP/IP; Terminal block 8I / 8O; Laser Safety Dedicated I/O; RS232; USB |
| Laser safety classification | Class 1 Door Closed / Class 2M door open (Aiming Diode) | Class 1 Door Closed / Class 2M door open (Aiming Diode) | Class 1 Door Closed / Class 2M door open (Aiming Diode) |
| Power consumption rate | 800W | 800W | 800W |
| Machine weight (without laser) | 60Kg (132,28 lbs) | 60Kg (132,28 lbs) | 60Kg (132,28 lbs) |
| Software | Lasertrace/Gravostyle | Lasertrace/Gravostyle | Lasertrace/Gravostyle |
